Building a Raspberry Pi Samba File Server with SSD (Access Files Anywhere!)

With a growing collection of documents, videos, project files, and backups, I decided to build a low-cost, power-efficient file server using my Raspberry Pi and a Samsung T7 SSD. I wanted global access, private sharing, and solid performance—and I achieved it all with Samba, ZeroTier, and some smart automation. Here’s how I turned my Raspberry Pi into a portable, secure Samba file server.

Sujit Rayaprolu

6/1/20252 min read

person holding blue and white box
person holding blue and white box

🧰 What I Used

  • Raspberry Pi 4 (8GB RAM)

  • Samsung T7 SSD (1TB)

  • Raspberry Pi OS (Lite version)

  • Samba (for file sharing)

  • ZeroTier (for secure remote access)

  • Static IP & Auto-mount on boot

⚠️ Challenges I Faced

1. SSD Auto-Mount Fails After Reboot

If you don’t properly mount the SSD using UUID in /etc/fstab, it might fail to mount at boot.

✅ Fix: Used blkid to get the UUID and configured fstab with correct mount options.

2. Samba Permissions Errors

Initially, I couldn’t write files to the share even though I could read them.

✅ Fix: Fixed ownership and permissions using chown and chmod, and ensured Samba was configured with the correct user mapping.

3. Global Access with Security

I didn’t want to expose my Pi to the open internet, so I needed a secure tunnel.

✅ Solution: I used ZeroTier to create a private mesh VPN and accessed Samba over it using my ZeroTier IP.

🛠️ Step-by-Step Setup Guide

📦 Step 1: Update Your Raspberry Pi

=> sudo apt update && sudo apt upgrade -y

🔌 Step 2: Connect & Mount Your SS

1. Plug in your SSD and Check if it’s detected:
=> lsblk

2. Format (Optional):

=> sudo mkfs.ext4 /dev/sda1

3. Mount SSD:

=> sudo mkdir /mnt/ssd sudo mount /dev/sda1 /mnt/ssd

4. Make It Permanent (Auto-mount on Boot):

Get UUID:

=> sudo blkid

=> sudo nano /etc/fstab

Add this line:

=> UUID=xxxx-xxxx /mnt/ssd ext4 defaults,nofail 0 0

Test it:

=> sudo mount -a

📁 Step 3: Install Samba

  • sudo apt install samba -y

  • Create a shared folder:

  • sudo mkdir /mnt/ssd/shared sudo chown -R pi:pi /mnt/ssd/shared sudo chmod -R 775 /mnt/ssd/shared

🔐 Step 4: Configure Samba

Edit the config file:

sudo nano /etc/samba/smb.conf

Add to the bottom:

path = /mnt/ssd/shared browseable = yes read only = no guest ok = no create mask = 0775 directory mask = 0775

Add your user to Samba:

sudo smbpasswd -a pi

Restart Samba:

sudo systemctl restart smbd

You can now access the share on:

🌐 Step 5: Enable Global Access with ZeroTier

Once authorized on your ZeroTier dashboard, you’ll get a virtual IP like 192.168.191.x. Access your share from anywhere:

🔒 Bonus: Improve Security

  • Use strong Samba passwords

  • Restrict access by IP if not using VPN

  • Regularly back up your config with rsync or rclone

🧠 Final Thoughts

Setting up a Samba server on the Pi with an SSD turned it into a compact NAS. With ZeroTier, I can now access files from anywhere securely—even from my Android phone or laptop on the go.

This project is perfect for:

  • Sharing files across your local or remote devices

  • Backups and media storage

  • Keeping your hacker tools synced (yes, even those 😎)

🔗 Project GitHub & Resources

📁 GitHub Repo: github.com/HardwareArchitect/pi-samba-server (coming soon)
🌐 Domain: sujit.cloud
📄 PDF Guide: Available on GitHub release page

Questions? Suggestions?
Feel free to reach out or fork my project! Let’s build a better personal cloud—one Pi at a time. 🚀
